Lab VIEW software with operating status display, tutorial feature and data acquisition via USB, running under Window 7 or Windows Vistaĭidactic Lab 2020-21 © Copyright | Civil Didactic Lab, Engineering Didactic Lab, Laboratory Workshop Equipments, Didactic Lab Suppliers, Didactic Lab Exporters.

Function for automated measuring of characteristic curves.

Solarcell trainer Patch#

Patch panel with bypass diodes and adjustable load resistance for selectable types of connection with individual cells.

Backing for solar cells with Peltier module for regulating temperature.Lighting unit with adjustable illuminance.Four mono crystalline silicon solar cells.The trainer include the following technical specifications: investigate Power degradation due to shading.Interconnect solar cells in parallel and series connection.Illustrate how illuminance and temperature affect the curves.Calculating current strength and achievable output.Be able to study physical behavior of solar cells under varying illuminance and temperature.Software with tutorials and data on load profiles for recording characteristic curves.

Regulated Peltier module for controlling the solar cell temperature.Trainer with four solar cells and bypass diodes that can be freely interconnected.The Solar cell measurement trainer system include the following descriptions or functions:
